Please kindly note that this product only work for 【DC 12 gasoline engine cars with electronic central door lock】.
it will not work for pickup and trucks and any cars with diesel engine!
An extra bypass module (Stock number: CA75TH5B91) is needed if your car with a chip key engine lock.
Main feature:
1. Arm/lock
2. Disarm/unlock
3. Panic code/Car finding
4. Push button start/stop
5. PKE-Passive keyless entry
6. Remote engine start/stop
7. Remote trunk release（Output +/- optional）
8. PKE on/off
9. Illegal door opening /ACC triggered
10. Central door locking automation
11. Emergency override
12. 15 minutes automatically engine cut off once the car is remote started if user does not step on foot brake pedal.
13. Keep pressing the button to start/stop the car
14. Code learning
Please note:
1.It is highly recommended to install this product by a professional technician.
2. If your car with chip keys, a immobilizer bypass module(Stock number: CA75TH5B91) will be required to bypass the engine lock to come with the function of remote engine start, Bypass module not included, sold separately.
3. There is a method on page 7 of [User manual] for installer to bypass the chip if without a bypass module in your hand.
Specifications:
main unit system:
Working Voltage: DC 12 V ± 3 V
Static Current: ≤ 15mA
PKE emission current: 40mA
Working Frequency: 433 – 434 MHZ
ACC / start current: 30A
Remote control:
Working Voltage: DC 3V
Operation Current: 8uA Static Current: ≤ 15mA
PKE emission current: 40mA
Battery: CR2032
you may also love another remote controller of this product, please search asin B07RYVQLZQ.
Package Dimensions : 7.72 x 5.31 x 2.64 inches; 1.7 Pounds
Batteries : 2 CR2 batteries required. (included)
Selling Start Date : May 3, 2022
Manufacturer : BANVIE
Stock number : CA9ZF8S3CR
Country of Origin : China
Basic Keyless Entry. remote control door/unlock, remote trunk release(+/-optional), car finding, direction light flashing, LED indicating
Keyless go smart ignition push button to start / stop your vehicle easily and conveniently.
PKE Passive Keyless Entry. lock or unlock the door when owner walk away or approach the car in 1-3 meters, PKE on/off optional.
Remote Engine Starter. remote engine start/stop to pre-warm or pre-cool your car in cold winter or hot summer,auto warm for 15min( a extra bypass is needed for car with chip key, and only remote start in arm status for safty )
Car alarm. in arm status, this system will alarming when door opening trigger or footbraked trigger, the siren will sound and direction light flash.
